TUBO MAYO GUEDEL Fleming SA Blackmagic Design DeckLink 8K Pro G2 4 channels 12G SDI capture and playback card up to 8K DCI. Specifiche tecniche Technical specs English description La seconda generazione della miglior scheda di acquisizione per il cinema digitale per la generazione di flussi di lavoro ad alta risoluzione, alto frame rate e alta gamma dinamica. Dotata di 4 connessioni quad link bidirezionali 12G SDI + HDMI 2. 1 per supportare tutti gli standard SD, HD, Ultra HD, 4K e 8K, la scheda di acquisizione e riproduzione PCIe 8K professionale definitiva progettata per la produzione di lungometraggi. Puoi anche utilizzare l'SDK DeckLink gratuito per configurare fino a 4 flussi video in qualsiasi direzione, formato o frame rate fino a 4K DCI 60p, per una vera acquisizione e riproduzione multicanale. DeckLink 8K Pro G2 supporta YUV 4: 2: 2 a 8 e 10 bit, nonch RGB 4: 4: 4 a 10 e 12 bit con colore full Rec. 2020. Inoltre, puoi lavorare fino a 120 fps in HD e 4K e fino a 60 fps in 8K. Le quattro connessioni 12G SDI supportano fino a 64 canali di audio incorporato. Technical characteristics Connections SDI video inputs: 4 x bi directional 12GSDI. Supports SD HD 2K 4K 8K, single, dual link and quad link 4: 2: 2 4: 4: 4. 2D 3D switchable SDI video outputs: 4 x bi directional 12GSDI. Supports SD HD 2K 4K 8K, single, dual link and quad link 4: 2: 2 4: 4: 4. 2D 3D switchable SDI audio inputs: 16 channels embedded in SD HD 2K. 64 channels embedded in 4K 8K. SDI audio outputs: 16 channels embedded in SD HD 2K. 64 channels embedded in 4K 8K. HDMI video inputs: 1 x HDMI 2. 1 HDMI video ouputs: 1 x HDMI 2. 1 HDMI audio inputs: 8 channels embedded in TMDS, 32 channels embedded in FRL HDMI audio ouputs: 8 channels embedded in TMDS, 32 channels embedded in FRL Sync input: Tri Sync or Black Burst Computer interface: PCI Express 8 lane generation 3, compatible with 8 and 16 lane PCI Express slots Supported codecs AVC Intra, AVCHD, Canon XF MPEG2, Digital SLR, DV NTSC, DV PAL, DVCPRO50, DVCPROHD, DPX, HDV, XDCAM EX, XDCAM HD, XDCAM HD422, DNxHR & DNxHD, Apple ProRes 4444, Apple ProRes 422 HQ, Apple ProRes 422, Apple ProRes LT, Apple ProRes 422 Proxy, uncompressed 8 bit 4: 2: 2, uncompressed 10 bit 4: 2: 2, uncompressed 10 bit 4: 4: 4 Software Software included: DaVinci Resolve, Media Express, Disk Speed Test, LiveKey, Blackmagic Desktop Video Utility and Blackmagic driver on Mac OS and Windows. Media Express, Blackmagic Desktop Video Utility and Blackmagic driver on Linux Internal software upgrade: firmware built into software driver. Loaded at system start or via updater software Physical installation PCI Express 8 lane generation 3, compatible with 8, 16 lane PCI Express slots on Mac OS, Windows and Linux. Requires 2 PCI slots plus connection to computer power supply. Please check the support pages to see the full system requirements SDI video standards SD video standards: 525i 59. 94 NTSC, 625i 50 PAL HD video standards: 720p 50, 720p 59. 94, 720p 60 1080p 23. 98, 1080p 24, 1080p 25, 1080p 29. 97, 1080p 30, 1080p 50, 1080p 59. 94, 1080p 60, 1080PsF 23. 98, 1080PsF 24, 1080PsF 25, 1080PsF 29. 97, 1080PsF 30 1080i 50, 1080i 59. 94, 1080i 60 2K video standards: 2K DCI 23. 98p, 2K DCI 24p, 2K DCI 25p, 2K DCI 29. 97p, 2K DCI 30p, 2K DCI 50p, 2K DCI 59. 94p, 2K DCI 60p 2K DCI 23. 98PsF, 2K DCI 24PsF, 2K DCI 25PsF, 2K DCI 29. 97PsF, 2K DCI 30PsF Ultra HD video standards: 2160p 23. 98, 2160p 24, 2160p 25, 2160p 29. 97, 2160p 30, 2160p 50, 2160p 59. 94, 2160p 60 4K video standards: 4Kp 23. 98 DCI, 4Kp 24 DCI, 4Kp 25 DCI, 4Kp 29. 97 DCI, 4Kp 30 DCI, 4Kp 47. 95 DCI, 4Kp 48 DCI, 4Kp 50 DCI, 4Kp 59. 94 DCI, 4Kp 60 DCI, 4Kp 95. 90 DCI, 4Kp 96 DCI, 4Kp 100 DCI, 4Kp 119. 88 DCI, 4Kp 120 DCI 8K video standards: 8Kp 23. 98 DCI, 8Kp 24 DCI, 8Kp 25 DCI, 8Kp 29. 97 DCI, 8Kp 30 DCI, 8Kp 47. 95 DCI, 8Kp 48 DCI, 8Kp 50 DCI, 8Kp 59. 94 DCI, 8Kp 60 DCI 3D SDI video standards: 720p 50, 720p 59. 94, 720p 60, 1080p 23. 98, 1080p 24, 1080p 25, 1080p 29. 97, 1080p 30, 1080p 47. 95, 1080p 48, 1080p 50, 1080p 59. 94, 1080p 60, 1080p 95. 90, 1080p 96, 1080p 100, 1080p 119. 88, 1080p 120, 1080PsF 23. 98, 1080PsF 24, 1080PsF 25, 1080PsF 29. 97, 1080PsF 30, 1080i 50, 1080i 59. 94, 1080i 60 2Kp 23. 98 DCI, 2Kp 24 DCI, 2Kp 25 DCI, 2Kp 29. 97 DCI, 2Kp 30 DCI, 2Kp 47. 95 DCI, 2Kp 48 DCI, 2Kp 50 DCI , 2Kp 59. 94 DCI, 2Kp 60 DCI, 2Kp 95. 90 DCI, 2Kp 96 DCI, 2Kp 100 DCI, 2Kp 119. 88 DCI, 2Kp 120 DCI, 2KPsF 23. 98 DCI, 2KPsF 24 DCI, 2KPsF 25 DCI, 2KPsF 29. 97 DCI, 2KPsF 30 DCI, 4Kp 23. 98 DCI, 4Kp 24 DCI, 4Kp 25 DCI, 4Kp 29. 97 DCI, 4Kp 30 DCI, 4Kp 47. 95 DCI, 4Kp 48 DCI, 4Kp 50 DCI, 4Kp 59. 94 DCI, 4Kp 60 DCI, 4Kp 95. 90 DCI, 4Kp 96 DCI, 4Kp 100 DCI, 4Kp 119. 88 DCI, 4Kp 120 DCI, 2160p 23. 98, 2160p 24, 2160p 25, 2160p 29. 97, 2160p 30, 2160p 47. 95, 2160p 48, 2160p 50, 2160p 59. 94, 2160p 60, 2160p 95. 90, 2160p 96, 2160p 100, 2160p 119. 88, 2160p 120 SDI compliance: SMPTE 259M, SMPTE 274M, SMPTE 292M, SMPTE 296M SMPTE 372M, SMPTE 424M, SMPTE 425M level A and B, SMPTE 20361, SMPTE 20481, SMPTE 208110, SMPTE 208111, SMPTE 208112, SMPTE 208210, SMPTE 208211, SMPTE 208212 and SMPTE ST21081 SDI metadata support: RP 188 SMPTE 12M 2 and closed captioning Audio sampling: television standard sample rate of 48 kHz at 24 bit SDI video sampling: 4: 2: 2, 4: 4: 4 SDI color precision: 8, 10, 12 bit RGB 4: 4: 4 in all modes up to 8K DCI 30p, and 8, 10 bit YUV 4: 2: 2 in all modes. Color space: REC 601, REC 709, REC 2020 Multiple rate support: SDI video connections are switchable between SD HD 2K 4K and 8K HDMI 2. 1 video standards SD video standard: 525i 59. 94 NTSC, 625i 50 PAL HD video standards: 720p 50, 720p 59. 94, 720p 60, 1080p 23. 98, 1080p 24, 1080p 25, 1080p 29. 97, 1080p 30, 1080p 47. 95, 1080p 48, 1080p 50, 1080p 59. 94, 1080p 60, 1080p 95, 1080p 96, 1080p 100, 1080p 119, 1080p 120, 1080i 50, 1080i 59. 94, 1080i 60 Ultra HD video standars: 2160p 23. 98, 2160p 24, 2160p 25, 2160p 29. 97, 2160p 30, 2160p 47. 95, 2160p 48 2160p 50, 2160p 59. 94, 2160p 60, 2160p 95, 2160p 96, 2160p 100*, 2160p 119, 2160p 120 4K video standards: 4Kp 23. 98 DCI, 4Kp 24 DCI, 4Kp 25 DCI, 4Kp 29. 97 DCI, 4Kp 30 DCI, 4Kp 47. 95 DCI, 4Kp 48 DCI, 4Kp 50 DCI, 4Kp 59. 94 DCI, 4Kp 60 DCI, 4Kp 95 DCI, 4Kp 96 DCI, 4Kp 100 DCI*, 4Kp 119 DCI*, 4Kp 120 DCI* 8K video standards: 4320p 23. 98, 4320p 24, 4320p 25, 4320p 29. 97, 4320p 30, 4320p 47. 95, 4320p 48, 4320p 50*, 4320p 59. 94*, 4320p 60* 8K DCI video standards: 8Kp 23. 98 DCI, 8Kp 24 DCI, 8Kp 25 DCI, 8Kp 29. 97 DCI, 8Kp 30 DCI, 8Kp 47. 95 DCI, 8Kp 48 DCI, 8Kp 50 DCI*, 8Kp 59. 94 DCI*, 8Kp 60 DCI* HDMI video sampling: 4: 2: 2, 4: 4: 4 and 4: 2: 0* HDMI color precison: 8, 10 and 12 bit* *supported video sampling and colour precision are dependent on connected HDMI device capabilities, video resolution and frame rate HDMI color space: REC 601, REC 709, REC 2020 HDR support: HDR static metadata packing, HLG and PQ transfer characteristics HDMI configuration: HDMI 2. 1 supports Deep Color and HDR. Automatically configures to connected display Multiple rate support: HDMI video connections are switchable between SD HD UHD and 4K Copy protection: HDMI input is unable to capture from copy protected HDMI sources. Always confirm copyright ownership before capture or distribution of content Processing Colorspace conversion: hardware based real time on output 3D processiong: left eye right eye dual stream capture and playback (SDI only) Real time effects: DaVinci Resolve, Final Cut Pro internal effects. Adobe Premiere Pro CC Mercury Playback Engine effects. Avid Media Composer internal effects Operating systems Mac 13. 0 Ventura, Mac 14. 0 Sonoma or later, Windows 10, 64 bit, Windows 11, Linux Software application Power requirements Power consumption: 30 W Environmental specifications Operating temperature: 5 to 50 C Storage temperature: 20 to 60 C Relative humidity: 0% to 90% noncondensing Physical specifications Dimensions: depth 16. 38 mm Weight: 295 g What's in the box DeckLink 8K Pro G2 HDMI 2. 1 mezzanine card External power cable Spacers and screws Welcome wallet with QR code for software download EN: The second generation of the best digital cinema capture card for high resolution, high frame rate, high dynamic range workflows. Featuring 4 bi directional Quad Link 12G SDI + HDMI 2. 1 connections to support all SD, HD, Ultra HD, 4K and 8K standards, it's the ultimate professional PCIe 8K capture and playback card designed for feature film production. You can also use the free DeckLink SDK to configure up to 4 video streams in any direction, format or frame rate up to 4K DCI 60p for true multi channel capture and playback. DeckLink 8K Pro G2 supports 8 and 10 bit YUV 4: 2: 2, as well as 10 and 12 bit RGB 4: 4: 4 with full Rec. 2020 color. Plus, you can work up to 120 fps in HD and 4K and up to 60 fps in 8K. The four 12G SDI connections support up to 64 channels of embedded audio.
